AirhandlingUnits

UNITECH-Kunststoff (UTE) GmbH
Eichenstraße 2
D-78256 Steißlingen

E-Mail

Click to enlarge	UNITECH Airhandling-Units are individual designed solutions for our customer requirements. In order to be able to comply with all technical requirements we can offer three different basic systems: Big size units in large panel construction (50mm sandwich panel) with PU-foam filling for airflow quantities up to 500.000 m3/h. High stability is achieved by the use of corrugated panels. This system offers nearly no constructional limitations. Standard units we herby use an aluminium frame construction with doubleskin panels (25mm or 50mm). The panels could be galvanized, made by stainless steel, coated or powder coated. Our units featuring themselves through an outstanding sound and heat insulation. Reinforced fibreglas units are special units constructed in the non-metallic material (reinforced fibreglas). This system becomes particularly interesting with especially aggressive air (for example acidic)like the chemical or pharmaceutical industrie. Somtimes It could also be an alterative to a stainless-steel unit. You will find some further information at Service/ Downloads. We are sure to find the solution even for your technical problem. Dont hesitate to contact us.	Click to enlarge
Click to enlarge		Click to enlarge
Click to enlarge		Click to enlarge
